Record No. 0230 Block Plane
Record No. 0230 Block Plane
as illustrated in Catalogue No. 15, February 1938
The Record No. 0120 block plane is fitted with a knuckle-joint lever cap which is made of steel and is nickel-plated. It has a screw adjustment on the cutter for regulating the depth of cut. The cutter is tightened in position by a nickel-plated knurled wheel and screw.
The base and sides are ground and polished, and there is a recess on each side for thumb and finger grip.
First introduced in Catalogue No. 11, published in September 1932.
Specifications:
| Manufactured: | From 1932 to 1943 |
| Length: | 6 inches |
| Weight: | 1-7/16 pounds |
| Cutter Width: | 1-5/8 inches |
| Construction: | Cast iron body, rosewood knob. Tungsten steel cutter |
| Finish: | Blue Enamel. Nickel plated lever cap & screw |
| Features: | Knuckle joint lever cap. Adjustable cutter |
| Uses: | General purpose block plane |
| Average Dealer Price: | $50 to $90 |
| Average eBay Price: | $40 to $70 |
| Prices Updated: | December 2008 |
